11. Move the harnesses to the back of the main unit.
Main Ink Level Sensor Bracket Removal
• The screws shown below are adjusted their position at the factory. Never loosen nor remove them
for changing or adjusting.
• A screw at the upper part of the air release solenoid bracket.
• Two screws at the lower part of the air release solenoid and main ink level sensor bracket.
4. Replacement and Adjustment
