13. Attach the clamps, route the harness, and then close the clamps ( x2).

Wiring Roll Unit 1

Connect Roll Unit 1 to the machine. The figure below shows the wiring example.

[A] IOB CN254

[B] Harness bracket of Roll Unit 1

2. Installation
