Paper Feed and Exit
Overview
No. Item No. Item
1 DRESS sensor 11 Roll end sensor
2 Platen 12 Encoder sensor 1 (motor)
3 Paper transport fan 13 Encoder sensor 2 (paper)
4 Registration roller 14 Spool
5 Bypass sensor 15 Roll rewind switch
6 Pre-registration sensor 16 Paper exit guide
7 Paper release sensor 17 Paper exit guide switch
Paper Feed and Exit
797
