Ink Collector Tank

1. Open the ink collector cover.

2. Depress the lever on the top of the ink collector to unlock it, and then remove it.

Paper Rolls

1. Make sure that the machine is switched on.

2. Raise the paper exit guide [A].

4. Replacement and Adjustment

232
