Ink Supply

No. Component Function

1 Ink cartridge cover switch Detects when the ink cartridge cover is opened and

closed.

2 Ink cartridge ID chip These ID chips identify each cartridge as the correct

type for the machine.

3 CCB Cartridge Control Board. Relays the ink cartridge ID

chip signals that confirm whether the ink cartridges

are installed correctly in the ink cartridge holder.
