Code/Area Jam Name & Description
After the original set sensor went OFF, the original registration sensor did not go
OFF within the prescribed time (after the original should have fed 20 mm).
5 Original exit sensor lag jam
The original exit sensor did not go off within the prescribed time (after the original
should have fed 20 mm).
6 Original stop jam
The [Original Stop] button on top of the scanner unit was pushed to remove the
original so that it could be set again.
7 Original exit late jam
After the original set sensor went ON, the exit sensor did not go ON within the
prescribed time (within the time the original should have fed 20 mm).
8 Next original set jam
The next original was set on the original feed table too early.
• The original set sensor detected the trailing edge of the first original.
• The paper set sensor detected the leading edge of the next original before
the IPU received the scan end signal.
Printer Paper Jams
Code Area Name
1 All Initial jam
2 B Main scan HP jam
8 A1 Pre-registration sensor lag jam (Roll Unit 1)
9 A2 Pre-registration sensor lag jam (Roll Unit 2)
13 B DRESS sensor late jam during image registration
16 C Exit sensor lag jam
34 B Bypass paper set jam
41 B Main scan printing jam
6. Troubleshooting
