CARRIAGE DRIVE
J001/J003 6-24 SM
6.6 CARRIAGE DRIVE
6.6.1 OVERVIEW
1. Horizontal Motor
2. Timing Belt
3. Guide Rod
4. Horizontal Encoder (Translucent Film)
1
2
3
4
