PREPARATION
SM 1-3 J001/J003
Installation
1.1.3 MINIMUM SPACE REQUIREMENTS
J001 A = 403 mm 15.9 in.
B = 440 mm 17.3 in.
C = At least 12 cm At least 5 in.
D = At least 17 cm At least 7 in.
J003 A = 490 mm 20 in.
B = 460 mm 18 in.
C = At least 12 cm At least 5 in.
D = At least 17 cm At least 7 in.
1.1.4 POWER SOURCE
North America 120 V, 60 Hz, more than 0.8 A
[A]
[B]
[C]
[D]
