Easy Removals
J007/J010/J011 3-4 SM
3.2 EASY REMOVALS
Switch the printer off and disconnect it from the power supply before you do the
procedures in this section.
To avoid ink spills, never turn the printer upside down or set it on either its left or
right side. The printer must always remain upright on a flat surface during
servicing.
3.2.1 TOP COVER (J011)
This procedure is for the J011 only. Before removing the top cover from the
J007/J010, you must remove another cover. This is described in the later section
"Top Cover (J007/J010)".
r000
1. Spread the hinge tabs slightly on the left and right side of the top cover.
2. Remove the top cover.
3.2.2 OUTPUT TRAY, PAPER FEED CASSETTE
1. Raise the output tray [A].
To Next Page
