Image Correction
SM 4-29 J007/J010/J011
J007/010/
J011
ENG SW #1 00001000
bit0 _
8. Push
or to display "1".
ENG SW #1 00001000
bit1 1
9. Push [#Enter] to set "1" for Bit SW 1.
10. After setting Bit 1 to "1", push [Escape] until the display returns to "ENGINE
MAINTE."
11. At "3. END" press [#Enter] to leave the SP mode.
12. Push [Menu] then select "Maintenance"> "3. Head-Flushing".
13. Select the one print head (or all) for drive cleaning and push [#Enter].
The print head is flushed. In addition to flushing, drive cleaning is also performed
with the piezo element switching on and off.
Once drive cleaning is completed for the selected print head, Bit 1 resets to "0"
automatically.
If you need to do this procedure again for another print head, you must repeat this
procedure and set Bit 1 to "1" again in the SP mode.
Drive cleaning cannot be performed if the ink tank of the selected print head is
almost empty.
4.5.8 CLEANING THE PRINT HEADS BEFORE LONG TERM
STORAGE
Do this procedure to clean the print heads before storing the printer for one month or
longer.
This procedure should be done at the Repair Center before storing a printer until
it can be reused. This procedure is not intended for use at the job site for the
customer.
1. Turn the printer on.
2. When the printer enters standby mode, enter the SP mode.
To enter the SP mode press
or together for at least 3 sec. then push
[#Enter].
3. Select "2. ENGINE MAINTE.".
To Next Page
