SERVICE INFORMATION
J006 16 SM
5. SERVICE INFORMATION
5.1 OPERATION PANEL FUNCTIONS
J001/J003 Manual Reference
5.1 Operation Panel Functions
Comment
Only the shapes of the keys on the operation panel have
changed. The operation of these keys is the same as with the
previous models.
1 Ink Level LEDs (K, C, M, Y)
2 [Power] Key
3 [Paper Feed] Key
4 [Cancel] Key
2
3 4
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
