IMAGE ADJUSTMENT
SM 3-19 J001/J003
Replacement
Adjustment
3.7.4 NOZZLE BLOCKAGE CHECK
One or more of the nozzles is blocked if you see these:
• Broken lines
• Uneven patches of white in the printouts.
At this time, do this procedure:
1. Open the printer driver. (3.7.2)
2. In the Printer Properties window click “Maintenance”>”Nozzle Blockage Check”.
3. Do the instructions on the screen to print the test pattern. The sample below
shows a normal and abnormal pattern.
4. Examine the pattern. Then check which color does not show. This information
will let you know which nozzle is blocked.
5. Do the instructions on the screen to select the color you want to correct. Then
clean the print heads.
Important:
• Do “Clean Print Heads (Normal)” up to 3 times to correct the problem. Do
“Clean Print Heads (Full)” once if the problem continues.
• The “Full” cleaning uses a lot of ink. Do not do the “Full” cleaning until you
have done the “Normal” cleaning at least 3 times.
• For more, please refer to Section “4. Troubleshooting”.
Normal Pattern
Lines are crisp and unbroken
.
Abnormal Pattern
Lines are broken, patches of white spoil the
appearance of the pattern.
To Next Page
