DETAILS
J006 20 SM
6.2 PRINT CARTRIDGE SET DETECTION
J001/J003 Manual Reference
6.4.3 Print Cartridge Set Sensor
Comment
New Features
The ID chips attached to the back of each ink cartridge not only store important
information about each cartridge (as described in the previous section) but also
perform the functions of print cartridge set sensors.
Each print cartridge has an ID chip. The machine can detect precisely which print
cartridge is missing or set improperly and issue a prompt to correct the problem.
This improves the precision of troubleshooting.
Because the micro switches of the J001/J003 were connected in series, the
operator did not know precisely which print cartridges were missing or improperly
set when a problem occurred.
