Image Correction
J007/J010/J011 4-28 SM
11. Select the paper tray and push [#Enter].
12. Select the paper type and push [#Enter].
13. Enter the adjustment for the Read Direction determined in Step 7 and push
[#Enter].
14. Enter the adjustment for the Feed Direction determined in Step 9 and push
[#Enter]
15. Push [Online] to leave the Menu mode.
4.5.7 DRIVE CLEANING
Follow the procedure below to do drive cleaning. Here are some important points you
should know about drive cleaning.
Drive cleaning should be done only after head cleaning and head flushing fail to clean
the print heads successfully.
Drive cleaning is done by changing a bit switch setting in the SP mode and should
always be done by the service technician.
Drive cleaning forces the piezo element to switch off and on repeatedly to force ink
out of the nozzle ports. (The piezo element does not operate during head cleaning or
head flushing done with the operator panel or the printer driver.)
Drive cleaning consumes more ink than either head cleaning or head flushing and
requires more time to complete.
Only one print head at a time can be cleaned with this procedure.
1. Push and hold down
and for 3 sec. then push [#Execute] to enter the SP
mode.
2. Push [#Enter].
3. Select "Engine Mainte."
4. When you see "SP No. 1000", select "5301" then push [#Enter].
5. When you see "ENGINE SW" push [#Enter].
6. Select "1" for Bit 1. This enables drive cleaning control.
Reading from left to right, the digits represents Bit 7 to 0.
"1" switches a bit ON and "0" sets a bit OFF.
The second line of the display contains the cursor. This tells you which bit is
currently active for selection.
ENG SW #1 00001000
bit0 _
Push [Escape] at any time if you want to return to the previous level.
7. Push
or to position the cursor under Bit 1 (2nd digit from the right).
