Electrical Component Functions
J007/J010/J011 6-34 SM
6.7 ELECTRICAL COMPONENT FUNCTIONS
6.7.1 MAIN BOARDS
PCB Abbreviation What It Means
CTL Control Board
CCB Cartridge Connector Board
DIB Duplex Interface Board
HRB Head Relay Board
OPU Operation Panel Unit
HVPS High Voltage Power Supply
PSU Power Supply Unit
