J007/J010/J011 36 Call Center Manual
Paper Tray (Tray 1) and Output Tray
First, always switch the printer off and disconnect the power cord from the power
source. Then disconnect all other cables (USB, etc.)
1. Pull the paper tray [1] straight out of the printer.
2. Press in both arms [2] and [3] of the output tray to release them then pull the
output tray out of the printer.
To Next Page
