Options
J007/J010/J011 1-18 SM
1.4 OPTIONS
1.4.1 NETWORK INTERFACE BOARD J508
The Network Interface Board is an option for the J007 printer only. The network board is
built into the J010/J011.
1. Check the type of printer to be installed:
The network interface board is built into the J010/J011, so the installation
procedure described below is not necessary.
However, the Network Interface Board J508 is an options for the J007 and must
be installed.
2. Make sure that the printer is switched off and disconnected from its power
source.
3. Turn the rear cover screw counter-clockwise and remove the cover.
4. Remove the spacer and discard it.
5. Before you touch the network interface board, touch a metal surface to ground
any static charge.
Handle the network interface board carefully.
To Next Page
