Installation Procedure
J007/J010/J011 1-16 SM
The paper size and type must be set with the menu on the operation panel.
Do the paper type setting for the paper loaded in the printer cassette (A4,
Plain or LT Plain, for example).
5. Press [Menu] key on the operation panel.
Select "Paper Input" then press [#Enter].
Select "Tray Paper Size" then press [#Enter].
Select "Tray 1" then push [#Enter].
Select the size of the paper loaded in the tray and press [#Enter].
Press [Escape] twice.
Select "Paper Type" and push [#Escape].
Select the type of paper loaded in the printer and push [#Enter].
6. If the bypass tray is installed, press [Escape] to return to the previous level and
do the same settings (paper size, paper type) for the bypass tray.
-or-
Press [Online] to leave the menu mode and return online.
7. Print the Configuration Page.
Push [Menu] on the operation panel.
Select "List/Test Print" and press [#Enter].
Select "Config. Page" and press [#Enter].
The Config. Page starts to print.
Push [Online] to return to standby mode.
1.3.7 DO THE USB CONNECTION
The printer driver and USB driver are on the installer CD-ROM provided with the printer.
You cannot use the USB cable to connect the printer and PC if you use Windows
95 or Windows NT 4.0. You must use a network connection.
You can only use the USB cable with Windows 98, Windows Me, Windows 2000,
Windows XP, or Windows Server 2003.
You must use USB 1.1 if you use Windows 98 or Windows Me. The printer is set
for "Auto Detection" by default. In this mode the printer can use either USB 1.1 or
USB 2.0.
1. Remove the paper seal from the USB port of the printer.
2. Mount the installer CD-ROM in the CD-ROM drive of the computer.
3. Follow the instructions on the screen to install the printer driver and USB driver.
Do not connect the USB cable until you are instructed to do so by the installer.
