SP Tables
J007/J010/J011 5-22 SM
5.2.6 GROUP 5000
Reset and Restoration Settings
5000 RST:FACT Restore Factory Default Setting
Resets and threshold settings and user adjusted values.
5001 RST:INIT CNT:F
Reset Initial Tank Fill Count to Manufacturing Operation
Count
Resets the initial fill counter to the initial factory setting (-2).
5002 RST:INIT CNT:A Reset Initial Tank Fill Count to Factory Shipping
Resets the initial fill counter to the initial factory setting before shipping (-1).
5003 RST:WASTE:R Reset Ink Collection Count/Flag: Right Ink Collection Unit
Resets the ink flag and ink counter for the right ink collection tank.
5004 RST:WASTE:L Reset Ink Collection Count/Flag: Left Ink Collection Unit
Resets the ink counter for the left ink collection tank.
Firmware Upload, Download
5005 NV:DOWNLOAD
Download Printer Firmware : Computer → Printer
Downloads the firmware data from a PC to the NVRAM (EEPROM) in the printer.
5006 NV:UPLOAD
Upload Printer Firmware: Printer → Computer
Uploads the firmware data from the NVRAM (EEPROM) in the printer to a PC.
Maintenance, Replacement
5007 WASHING Execute Auto Washing
Executes the automatic flushing procedure.
5100 PURGE:MAINTE Purge Maintenance: Right Vent
Moves the carriage in order to access the right air vent for cleaning.
5101
CARRIAGE
CHANGE
Set Printer in Carriage Replace Mode
Use this SP to reset the print head rank setting after print head replacement and
to re-initialize the initial filling counter.
Carriage Replacement Flow
1. Enter the print head rank (wave) of
Print head 1.
Print head 2.
Print head 3.
Print head 4.
2. Enter the print head rank (voltage) of
To Next Page
