Before You Begin
SM 5-1 J007/J010/J011
J007/J010
J011
5. SERVICE TABLES
5.1 BEFORE YOU BEGIN
5.1.1 ENTERING/EXITING SP MODE
To enter SP Mode
1. Push and hold down
and together for at least 3 sec then release.
2. Push [#Enter].
To exit SP mode
1. Press
or to display "3. End" on the LCD.
2. Push [#Enter] to leave SP mode and return to the normal operation display.
5.1.2 USING THE SP MENUS
The system version number appears on the LCD after the printer enters the SP mode.
This is the top menu, the initial SP mode selection screen.
Top Menu
There are three selections on the top menu.
1. Service Menu.
2. Engine Mainte.
3. End.
To select and open one of these press the
or to display the item, then push [#Enter].
Every menu display is a rolling display.
If you press
with the first item on the LCD, the display will rotate to the last
item.
If you press
with the last item on the LCD, the display will rotate to the first
item.
Selecting Menu Items
1. Push or to display "1. Service Menu".
2. Push [#Enter].
3. If you see ">>" on the right side of the LCD, this means there are more menu
selections on the same level. Push
or to display group number of the SP
mode that you want to open.
4. Press [#Enter].
