103
Key Adjustments (Menus)
Chapter 4 Keys
5
To adjust the color, press [Zabton Color] and adjust
the following parameters.
Masks
There are two masks, which can be used to mask off
unneeded parts of a key or background, or to remove
defects, and these are known as the main mask and
subsidiary mask.
You can either use the main mask and subsidiary mask
independently, or at the same time.
Using the main mask
For example, to use the main mask for key 1 on the M/E-1
bank, use the following procedure.
1
In the M/E-1 >Key1 menu, select HF3 ‘Main Mask.’
The Main Mask menu appears.
2
In the <Mask Type> group, select the mask type.
Key Mask: Masks a part of a key.
Bkgd Mask: Masks a part of a background.
3
In the <Mask Source> group, select the mask source.
Box: signal from the dedicated box generator
Pattern: signal from the dedicated pattern generator
4
Set the mask source parameters.
When a box is selected
When a pattern is selected
a) The pattern is the same as a standard wipe. (See “Wipe Pattern List”
in Appendix (Volume 1) (page 308).)
To select the pattern, display the Mask Ptn Select
menu by pressing the [Mask Ptn Select] button in the
Main Mask menu.
After selecting one of the patterns (standard wipe
patterns 1 to 24) displayed in the Mask Ptn Select
menu, you can adjust the following parameters.
5
To invert the black and white sense of the mask source,
press the [Mask Invert] button, turning it on.
6
When a pattern is selected as the mask source, set the
pattern modifiers as required.
When turning [Position] on and setting the pattern
position
a) See page 130.
When turning [Multi] on and replicating the
pattern
a) See page 132.
When turning [Aspect] on and setting the aspect
ratio of the pattern
a) See page 132.
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
4 Density Density 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Top Top position –100.00 to
+100.00
2 Left Left position –100.00 to
+100.00
3 Right Right position –100.00 to
+100.00
4 Bottom Bottom position –100.00 to
+100.00
5 Soft Box softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
5 Pattern Pattern number 1 to 24
a)
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal
position
–200.00 to
+200.00
a)
2 Position V Vertical position –200.00 to
+200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of
repetitions of
pattern
horizontally
1 to 63
2 V Multi Number of
repetitions of
pattern vertically
1 to 63
3 Invert Type Replication
layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio –100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
To Next Page
