197
Color Corrector Functions
Chapter 9 Color Corrector
When turning [Position] on and setting the pattern
position
a) See “Setting the wipe position (Positioner)” (page 130).
When turning [Multi] on and replicating the same
pattern
a) See “Setting the wipe pattern replication (Multi)” (page 132).
When turning [Aspect] on and setting the aspect
ratio of the pattern
a) See “Setting the wipe pattern aspect ratio (Aspect ratio)” (page 132).
When turning the [Angle] on in the <Rotation>
group and slanting the pattern
a) See “Angle” (page 131).
When turning [Speed] on in the <Rotation> group
and rotating the pattern at a fixed rate
a) See “Speed” (page 131).
7
To invert the mask source, return to the Primary CCR
menu and press [Pri/Sec Mask Invrt], turning it on.
The mask function is common to the primary color
correction, secondary color correction, and spot color
adjustment functions.
Secondary Color Correction
Operations
For the six colors R (red), G (green), B (blue), Y (yellow),
C (cyan), and M (magenta), adjust the luminance and
saturation, and also the hue within a range of ±30 degrees
of the center value for each color.
You can mask a part of the region to be corrected.
Applying secondary color correction
1
In the CCR menu, press VF1 ‘CCR1’ and HF3
‘Secondary CCR.’
The Secondary CCR menu appears.
2
In the <Secondary CCR> group, press [Secondary
CCR], turning it on.
3
In the <Secondary CCR Adjust> group, select the
color for which you want to make the setting.
4
Adjust the following parameters.
To return the parameter settings to their default
values
In the <Secondary CCR> group press [Unity].
Masking a part of the secondary color
correction
Set [Mask] to On in the Secondary CCR menu, then carry
out the same operation as described under “Masking a part
of the primary color correction” (page 196).
Luminance Processing Operations
After converting a signal to which RGB color correction
has been applied to a YUV signal, divide the luminance
levels into three regions, referred to as Dark, Middle, and
Bright, and apply video signal adjustments to these
regions.
Knob Parameter Adjustment Setting values
1 Position H Horizontal
position
–200.00 to +200.00
a)
2 Position V Vertical
position
–200.00 to +200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of
repetitions of
pattern
horizontally
1 to 63
2 V Multi Number of
repetitions of
pattern
vertically
1 to 63
3 Invert Type Replication
layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect aspect ratio
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of
pattern
rotation
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation
rate of
pattern
–100.00 to +100.00
a)
Notes
Knob Parameter Adjustment Setting values
1 Luminance Luminance –100.00 to +100.00
2 Saturation Saturation 0.00 to 200.00
3 Hue Delay Hue delay –180.00 to +180.00
