Applying Special Effects (Effects on the Overall Video Signal)
Chapter 11 DME Operations
When Video/Key is selected (with SDI-interfaced
DME)
When video is selected (with SDI-interfaced DME)
When Key is selected (with SDI-interfaced DME)
Masking the Blur effect with a selected
pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Multi Move Settings
Applying the Multi Move effect
1 In the DME menu, select VF2 ‘Video Modify’ and
HF2 ‘Multi Move.’
The Multi Move menu appears.
2 Press [Multi Move], turning it on.
3 Set the parameters.
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
4:3 mode
2V Vertical
defocusing of
video and
key signals
0.00 to 100.00
3All Horizontal
and vertical
defocusing of
video and
key signals
H value shown
Parameter group [1/2]
Knob Parameter Adjustment Settings values
1 V/K H Horizontal
defocusing of
video and
key signals
Video H value
shown
2 V/K V Vertical
defocusing of
video and
key signals
Video V value
shown
3 V/K All Horizontal
and vertical
defocusing of
video and
key signals
Video H value
shown
4 Video All Horizontal
and vertical
defocusing of
video signal
Video H value
shown
5 Key All Horizontal
and vertical
defocusing of
key signal
Key H value shown
Parameter group [2/2]
Knob Parameter Adjustment Settings values
1 Video H Horizontal
defocusing of
video signal
0.00 to 100.00
2 Video V Vertical
defocusing of
video signal
0.00 to 100.00
3 Key H Horizontal
defocusing of
key signal
0.00 to 100.00
4 Key V Vertical
defocusing of
key signal
0.00 to 100.00
Knob Parameter Adjustment Settings values
1H Horizontal
defocusing of
video signal
0.00 to 100.00
Knob Parameter Adjustment Setting values
2V Vertical
defocusing of
video signal
0.00 to 100.00
3All Horizontal
and vertical
defocusing of
video signal
H value shown
Knob Parameter Adjustment Setting values
1H Horizontal
defocusing of
key signal
0.00 to 100.00
2V Vertical
defocusing of
key signal
0.00 to 100.00
3All Horizontal
and vertical
defocusing of
key signal
H value shown
Knob Parameter Adjustment Setting values
1 Center X x-value of
shrinking
center point
–4.00 to +4.00 (SD)
–12.00 to +12.00
(HD)
2 Center Y y-value of
shrinking
center point
–3.00 to +3.00 (SD)
–9.00 to +9.00 (HD)
3Size Shrinking
ratio
0.00 to 100.00
Knob Parameter Adjustment Settings values
