521
Operation Settings (Operation Menu)
Chapter 19 Control Panel Setup (Panel)
1
In the Panel >Operation >Custom Button menu, press
[Next Trans All].
The Next Trans All menu appears.
2
Press the button for the next transition you want to
select with the [ALL] button, turning it On.
Setting Trackball, Joystick, Search
Dial, and Double-Click Sensitivity
You can set the operational sensitivity for trackball,
joystick and the buttons which recall the relevant menus
when pressed twice, and the relation of the rotation angle
of search dial with the playback speed.
1
In the Panel >Operation menu, press the [Sensitivity].
The Sensitivity menu appears.
The status area shows a list of the items with their
settings.
2
Make the following settings as required.
Trackball and Z-ring sensitivity in normal mode:
In the <Trackball Normal Mode> group, select
[×1], [×2], or [×4].
Trackball and Z-ring sensitivity in fine mode: In the
<Trackball Fine Mode> group, select [
1
/
2
], [
1
/
4
],
or [
1
/
8
].
Joystick sensitivity in normal mode: In the <Joystick
Normal Mode> group, select [×1], [×2], or [×4].
Joystick sensitivity in fine mode: In the <Joystick
Fine Mode> group, select [
1
/
2
], [
1
/
4
], or [
1
/
8
].
Touch sensitivity for recalling menus by double-
clicking buttons: In the <Double Click> group,
select [Fast], [Normal], or [Slow].
Making advanced settings for the search
dial
1
In the Panel >Operation >Sensitivity menu, press
[Search Dial].
The Search Dial menu appears.
The status area shows a list of the settings and their
content.
2
Set the sensitivity for the search dial in jog mode.
When operated with the [JOG] button pressed to
be lit amber: In the <Jog Sensitivity> group,
press one of [1 (Slow)] to [6 (Fast)].
When operated with the [JOG] button held down:
In the <Jog Sensitivity (While pressing [JOG]
button)> group, press one of [1 (Slow)] to [6
(Fast)].
3
In the <SHTL/VAR Dial Range> group, select
[Narrow] or [Wide] to set the sensitivity for the search
dial in shuttle mode or variable mode.
Narrow: The search speed varies in a relatively
narrow range.
Wide: The search speed varies in a relatively wide
range.
For details of search dial operations, see “Controlling the
Tape/Disk Transport” (page 367).
Specifying Main Split Fader
In the <Main Split Fader> group of the Panel >Operation
menu, select [Left] or [Right].
This setting is disabled for the CCP-9000A.
Setting the Macro Execution Mode
1
Press [Macro] in the Panel >Operation menu.
The Macro menu appears.
2
In the <Macro Execution Mode> group, select the
macro execution mode.
Normal: normal execution mode
Step: step execution mode
3
In the <Flexi Pad Edit Mode> group, set the macro
editing mode of the standard type Flexi Pad to [Pause
Only] or [Full Editing].
This enables the standard type Flexi Pad control block
to be used for macro editing. Depending on the macro
editing mode setting, functions are assigned to the
memory recall buttons as shown in the following
figure.
Notes
When the setting is
[Pause Only]
When the setting is
[Full Editing]
To Next Page
