Sony MVS-7000X User Manual

240
Applying Special Effects (Edge Effects)
Chapter 11 DME Operations
Applying Special Effects
(Edge Effects)
Border Settings
Adding a border
1 In the DME menu, select VF1 ‘Edge’ and HF1
‘Border/Crop.’
The Border/Crop menu appears.
2 Press [Border], turning it on.
3 Set the parameters.
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
4:3 mode
16:9 mode
Setting the border color
The operation differs depending on the DME used (MVE-
8000A, MVE-9000 or MKS-7470X/7471X).
When the MVE-8000A is used
Press [Border Color], turning it on, and set the following
parameters.
When the MVE-9000 or MKS-7470X/7471X is used
Use the buttons in the <Border Fill> group to select the
signal to insert in the border.
Flat Color: single color
Mix Color: mix color signal set in the Color Mix menu
(see page 253)
Ext Video: an external video signal input to the Ext IN
connector
If Flat Color is selected, adjust the following parameters.
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Border width
on left and
right sides
Left value shown
2 V Border width
on top and
bottom sides
Top value shown
3 All Border width
on all sides
Left value shown
5 Density Border
density
0.00 to 100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Border width
on top side
–6.00 to +6.00 (SD)
–18.00 to +18.00
(HD)
2 Left Border width
on left side
–8.00 to +8.00 (SD)
–24.00 to +24.00
(HD)
3 Right Border width
on right side
–8.00 to +8.00 (SD)
–24.00 to +24.00
(HD)
4 Bottom Border width
on bottom
side
–6.00 to +6.00 (SD)
–18.00 to +18.00
(HD)
5 Density Border
density
0.00 to 100.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Border width
on left and
right sides
Left value shown
2 V Border width
on top and
bottom sides
Top value shown
3 All Border width
on all sides
Left value shown
5 Density Border
density
0.00 to 100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Border width
on top side
–4.50 to +4.50 (SD)
–18.00 to +18.00
(HD)
2 Left Border width
on left side
–8.00 to +8.00 (SD)
–32.00 to +32.00
(HD)
3 Right Border width
on right side
–8.00 to +8.00 (SD)
–32.00 to +32.00
(HD)
4 Bottom Border width
on bottom
side
–4.50 to +4.50 (SD)
–18.00 to +18.00
(HD)
5 Density Border
density
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
