548
Interfacing With External Devices (Device Interface Menu)
Chapter 20 Switcher Setup (Switcher)
3
To select the number of keys that use DME on an M/E
bank, make one of the following selections in the
<DME Assignment for Proc Key> group.
Single DME unit: Mode in which a processed key
operation is carried out only with the dedicated
interface DME or the SDI interface DME.
Dual DME units: Mode in which two processed key
operations with the dedicated interface DME and
the SDI interface DME are both possible
simultaneously on the same M/E. When this mode
is selected, when combined by a processed key
with the SDI interface DME, select the material
for the second channel not on the DME external
video bus, but on the AUX bus.
Setting the AUX Bus Output and
Reentry Input
Select the signal input to the DME (AUX bus output) and
the signal returned as the switcher primary input (reentry
input) as follows.
1
In the Switcher >Device Interface menu, press [DME
Type Setting].
The DME Type Setting menu appears.
2
Press [DME SDI Interface].
3
Using any of the following methods, select the DME
channel to which operations apply.
• Press directly on the list on the left of the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
When using the MVE-8000A, it is not possible to
select any of DME 1 Ext In to DME 8 Ext In.
4
In the <Select> group, select the AUX bus or reentry
to be assigned to the DME channel.
Aux Bus: Set AUX bus.
Re-Entry: Set reentry.
5
Depending on the selection in step 4, use any of the
following methods to make the setting.
• Press directly on the list on the right of the status
area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
When Aux Bus is selected
When Re-Entry is selected
6
Press [Set].
In the list on the right of the status area, the selected
content is reflected in the specified DME channel.
Repeat steps 3 to 6 as required.
Selecting the Mode for Turning Off
Keys Upon Receiving the Editor
Command
Selects the mode for turning off keys when an “All Stop”
command is received from the editor.
1
In the Switcher >Device Interface menu, press [Editor
I/F].
The Editor I/F menu appears.
2
Select one of the following modes.
All: When an “All Stop” command is received, all
keys for the selected regions are turned off.
Specified: When an “All Stop” command is received,
among all the keys for the selected regions, only
the keys specified by the editor are turned off.
When an “All Stop” command is received in the
process of a transition, the keys selected for the next
transition are also turned off.
Knob Parameter Adjustment Setting values
1DME Ch
No
DME channel
selection
1 to 24
Notes
Knob Parameter Adjustment Setting values
2 Src No AUX bus number 0 to 48
Knob Parameter Adjustment Setting values
2 Src No Reentry number 0 to upwards
Notes
