217
M/E Configuration Switching
Chapter 10 Special Functions
Video Creation in 3D Mode
Adjusting the parallax using the DME
By adjusting the parallax (see page 211), you can control
the degree of depth perception.
1
Display the Global Effect >Ch1 to Ch4 >3D Mode
menu.
2
To adjust the parallax, press [Parallax].
3
Turn the knobs to adjust the following parameters.
If the position of an image in three-dimensional space
is in the plane of the monitor screen, adjusting the
parallax does not change the 3D effect. In this case,
adjust the parameters in the local coordinate space so
that the image is either in front of or behind the plane
of the screen before adjusting the parallax.
4
To adjust the perspective without changing a size or
shape, press [Disparity].
5
Turn the knobs to adjust the following parameters.
M/E Configuration
Switching
On the MVS-7000X, a single mix/effect board MKS-
7210X can be shared among a number of M/E banks.
Using this function, you can select the M/E configuration
of the whole switcher from the following.
In this manual, using a single MKS-7210X board is
referred to as 1M/E mode, 2M/E mode, 3M/E mode, or
4M/E mode depending on the maximum number of M/Es
on which the board is used.
• A maximum of five M/Es can be used on a single
switcher.
• When the signal format is 1080P, each MKS-7210X
board can only be used on a single 1M/E and the number
of available keys is 4.
• In 2M/E mode, DME selection on a single M/E is as
follows.
- Two places when the dedicated interface is used.
- One place when the SDI interface is used.
Setting the number of M/Es for each board
Use the following procedure.
1
Display the Engineering Setup >System > Install/Unit
Config >M/E Split menu.
2
In <M/E Split (1st Board)> group, select any of
[1ME], [2ME], [3ME], and [4ME].
3
In each of the <M/E Split (2nd Board)> to <M/E Split
(3rd Board)> groups, select [1ME] or [2ME].
4
Press [Execute].
Knob Parameter Adjustment Setting values
11ch
Parallax
Adjust the
parallax for
channel 1
0.00 to 8.00
22ch
Parallax
Adjust the
parallax for
channel 2
0.00 to 8.00
Notes
Knob Parameter Adjustment Setting values
11ch
Disparity
Adjust the
degree of depth
perception for
channel 1
–8.00 to 8.00
22ch
Disparity
Adjust the
degree of depth
perception for
channel 2
–8.00 to 8.00
Board Number of
assigned M/Es
Number of keys available on
a single M/E
Board 1 1 8
24
3 M/E-1, M/E-2 Select from
0 to 4
PGM/PST 4
4 Select from 0 to 4
Board 2 1 8
24
Board 3 1 8
24
Notes
