185
Copy and Swap
Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
Matte data copy and swap
You can copy or swap the matte data among the color
generators listed in the following table.
Color data copy and swap
You can copy or swap the color data among the color
generators listed in the following table.
DME channel copy and swap
You can copy and swap the channel data among DME
channels 1 to 4 or DME channels 5 to 8.
It is not possible to copy or swap the channel data between
DME channels 1 to 4 and DME channels 5 to 8.
On the MVS-8000X, when the signal format is 1080P, the
combinations for a copy or swap are restricted as follows.
• Channels 1 and 2
• Channels 3 and 4
• Channels 5 and 6
• Channels 7 and 8
On the MVS-7000X, when the signal format is 1080P, the
above restriction also applies if using the MVE-8000A.
There is no such restriction for the MKS-7470X/7471X.
Copying format converter data
You can copy data from one format converter input to
another or from one output to another.
The copy source and destination data must be in the same
signal format.
Copy and Swap Operations
Copy and Swap Menu Operations
In the menu operation section top menu selection buttons,
press the [Copy/Swap] button, then press VF1 ‘Copy/
Swap.’ The Copy/Swap menu appears.
Here a copy/swap operation on wipe data is described by
way of example, using the Copy/Swap >Wipe menu, but
the same general procedure applies to all of the following
menus.
• M/E: Copying and swapping M/E data
• Key: Copying and swapping key data
• Wipe: Copying and swapping wipe data
• DME Wipe: Copying and swapping DME wipe data
• Matte: Copying and swapping matte data
• Color: Copying and swapping color data
• DME: Copying and swapping data by DME channels
• Format Converter: Copying format converter data
For an overview of the concepts involved, see “Copy and
Swap” (page 184). For details of color corrector copy
and swap, see “Copy and Swap Operations” (page 194).
Examples of Copy and Swap Operations
by a Menu Operation
As an example, to copy or swap wipe data, use the
following procedure.
1
In the Copy/Swap menu, select HF3 ‘Wipe.’
The Copy/Swap >Wipe menu appears.
The status area shows lists for the copy/swap source on
the left, and the copy/swap destination on the right.
2
In the <Data Select> group, select either of the
following.
Target
bank
Target keyer Target data
M/E-1 Keys 1 to 8 DME wipe settings in the
independent key
transition control block.
PGM/
PST
Downstream keys 1 to 8
Target
bank
Target keyer and data
M/E-1
PGM/PST
•Keys 1 to 8
• Downstream keys
1 to 8
• Matte data for key fill
• Matte data for key
edge fill
Matte data for wipe border edge
Color
background
• Matte data for color background 1
• Matte data for color background 2
Target
bank
Target keyer and data
M/E-1
PGM/PST
•Keys 1 to 8
• Downstream keys
1 to 8
• Colors 1 and 2 for
key fill
• Colors 1 and 2 for
key edge fill
• “Zabton” color data
Colors 1 and 2 for wipe border
Color data for preset color mix
Color
background
• Colors 1 and 2 for color background 1
• Colors 1 and 2 for color background 2
Frame
memory
•FM1 color
•FM2 color
DME ch1 to
ch4
•Background
• Border
• Sepia
•Light
• Shade
• Drop shadow (other than DME ch4)
•Trail
Notes
