Three-Dimensional Transformation Operations
Chapter 11 DME Operations
Three-Dimensional Parameter
Display
You can check the values of the three-dimensional
parameters in the DME menu.
Displaying the three-dimensional
parameters in the DME menu
In the menu control block, select the top menu selection
button [DME].
The DME menu appears. The status area shows the three-
dimensional parameters currently controlled by the device
control block.
• When multiple DME channels are selected, this shows
the parameters for the reference channel.
• When both Global and Local are selected, the three-
dimensional parameters are shown for the channel (the
reference channel) for which the button is lit green.
Example three-dimensional parameter display (DME menu)
Viewing the three-dimensional parameter
details
In the DME menu, press the menu title button (the [DME]
in the upper left part of the screen).
The Status menu appears. This menu shows the three-
dimensional parameters for the DME reference channel
currently selected in the device control block.
Example three-dimensional parameter details
Entering Three-Dimensional
Parameter Values
In addition to setting three-dimensional parameter values
with the trackball and Z-ring, you can enter them directly
from the numeric keypad control block.
Entering three-dimensional parameter
values
1
In the device control block, press the [X], [Y], or [Z]
button, turning it on.
SHIFT+
ROT
Source,
target
Rotate
image on
y-axis
(Spin
mode)
Rotate
image on
x-axis
(Spin
mode)
Rotate
image on
z-axis
(Spin
mode)
AXIS
LOC
Source Move x-
axis of
rotation
Move y-
axis of
rotation
Move z-
axis of
rotation
LOC
SIZE
Source,
target
Move
image on
x-axis
Move
image on
y-axis
Magnify
and shrink
ASP
PERS
Source Change
aspect
ratio on x-
axis
Change
aspect
ratio on y-
axis
Change
aspect
ratio on x-
and y-
axes
simultane-
ously
Target Shift view
point on x-
axis
Shift view
point on y-
axis
Change
distance
from view
point to
SHIFT+
ASP
PERS
Source Change
skew on x-
axis
Change
skew on y-
axis
Change
aspect
ratio on x-
and y-
axes
simultane-
ously
Functions assignable to joystick operations
Button Usable
coordinate
space
Joystick
x-
direction
Joystick
y-
direction
Joystick
z-
direction
Type of three-
dimensional space
a)
Operation mode for
three-dimensional
transforms
b)
Value of X
Value of Y
Value of Z
a) This shows one of Local Target, Local Source, Global Target,
and Global Source.
b) This shows one of Loc XYZ, Loc Size, Rot, Spin, Axis Loc,
Skew, Asp, and Pers.
