Multi Program 2
Chapter 10 Special Functions
• Assigning sub preview output to preview selection
buttons in the fade-to-black control block
• Changing the matrix size to Standard
• Making settings for keyframe timeline operation
Basic Operations (Required)
Entering the install key of the software
(first time only)
After installing the BZS-8200X or the BZS-7200X Multi
Program 2 software in the switcher, carry out the following
procedure.
1
In the status area of the Engineering Setup >System
>Install/Unit Config menu, select the switcher
(SWRx), and press [License].
The License menu appears.
2
In the License menu, enter the install key.
For details of the operation, see “Installation and
Device Setup (Install/Unit Config Menu)” in
Chapter 18 (Volume 2).
3
Shut down the menus (see page 55).
4
Power the switcher and SCU off and on again.
Setting the operating mode for each
switcher bank
To set a desired switcher bank to Multi Program 2 mode,
use the following procedure.
1
Display the Engineering Setup >Switcher >Config
menu.
2
Select the switcher bank from M/E-1 to M/E-4, and P/
P.
3
In the <M/E Config> group, select [Multi Program2].
4
Repeat steps 2 and 3 as required, to set the operating
mode for all desired switcher banks.
Assigning output signals for Multi
Program 2 mode
To assign signals to outputs
Use the Engineering Setup >Switcher >Config >M/E
Output Assign menu.
The difference from standard mode is that OUT1 is fixed,
set to PGM1 (main program), and OUT6 is fixed, set to
PGM2 (sub program), and that for the OUT2 to OUT5
signals you can assign any signal selected from the
following.
PGM1, PGM2, PGM3, PGM4, PVW1, PVW2, K-
PVW1, K-PVW2, CLEAN, SUB CLEAN
Each of main and sub can use a maximum of four of the six
outputs (OUT1 to OUT6). The outputs can be used within
the following limits.
• OUT1, OUT2: main only
• OUT3, OUT4: can be used for either main or sub
• OUT5, OUT6: sub only
For details, see “Selecting the System Operation Mode” in
Chapter 18 (Volume 2).
To set the background and key configuration
Use the Engineering Setup >Switcher >Config >PGM
Config menu.
The following are the differences from standard mode.
Background configuration: Consists of the following
combinations.
• For main: Clean, Bkgd A, Bkgd B
• For sub: Sub Clean, Utility 2, Utility 3
Key configuration: Key1 can be set to “Enable” only
when the background is Clean, Bkgd A, or Bkgd B.
For details, see “Setting the Operation Mode” in
Chapter 20 (Volume 2).
To set the key preview configuration
Use the Engineering Setup >Switcher >Config >K-PVW
Config menu.
The following are the differences from standard mode.
Background configuration: Clean or Sub Clean
Key configuration: Key1 can be set to “On” or “Link”
only when the background is Clean.
For details, see “Setting the Operation Mode” in
Chapter 20 (Volume 2).
To assign sub outputs to output ports
Use the Engineering Setup >Switcher >Output >Output
Assign menu.
You can assign a sub output signal to a switcher output
port number.
For details, see “Assigning Output Signals” in Chapter 20
(Volume 2).
Assigning main and/or sub to switcher
banks
For each switcher bank for which Multi Program 2 mode
is selected, set whether this is main dedicated, sub
dedicated, or main and sub shared.
