169
Frame Memory Clip Operations
Chapter 7 Frame Memory
2
In the frame memory selection area, select an assigned
target FM. (See page 161).
3
If [Direct Recall] is on, press the button, turning it off.
4
In the frame memory folder selection area, select the
desired folder.
By pressing [More] to switch the displays, you can
select from a maximum of 12 folders.
5
Using the arrow keys or turning the knob, scroll the
file thumbnail display.
6
Press the thumbnail of the clip you want to recall.
7
Press [Recall].
This recalls the clip file, which is assigned to the FM
you selected in step 2.
In pair mode, if a clip is selected, the main file is output
to FM1, and the sub file to FM2. In single mode, when
only one of FM1 and FM2 is selected, the front file on
the thumbnail is output.
To recall in direct recall mode
Direct recall means that pressing a thumbnail immediately
recalls the file.
In this mode, only the front thumbnail file is recalled.
1
In step 7 above, instead of pressing [Recall], press
[Direct Recall].
2
Press the thumbnail for the file you want to recall.
To display the subsidiary file in front
With the direct recall mode on, press [Sub Display],
turning it on.
To search the clip file by file name
Press the [Find] button (see page 164).
Clip Playback
You can play a recalled clip by a menu operation or by
using the device control block.
With a pair file recalled, it is possible to set [Pair] to Off
and carry out a single file operation, but if you then set
[Pair] to On again, the output of frame memory may be
black. In such cases it is necessary to recall the pair file
once more.
Playing a clip using the menu
1
In the Frame Memory menu, select VF2 ‘Clip’ and
HF2 ‘Play.’
The Play menu appears. The status of the clip shown
in the current target FM selection buttons appears here.
2
When [Pair] is Off, press a target FM selection button
to select the target.
Knob Parameter Adjustment Setting values
1 Scroll Thumbnail
display
scrolling
1 and upwards
Target selection buttons
Pair selection buttons
Clip file selection area
Frame memory
selection area
Frame memory
folder selection area
Direct Recall button
Find button
Notes
Playback start point
(pale blue bar)
Current position
(red bar)
Status buttons
These show the timecode
values for the start point,
current position, and end
point.
Playback end point
(yellow bar)
To Next Page
