470
System Settings (System Config Menu)
Chapter 18 System Setup (System)
• When making DME settings for SWR2, for the
first DME, select [DME3] in the <1st DME> group.
For the second DME, select [DME4] in the <2nd
DME> group. When a second DME is not
connected, turn all buttons in the <2nd DME> group
off.
If you use the MKS-7470X/7471X, select either
DME1 or DME3.
When the signal format is 1080P
You can connect up to four MVE-8000A units to SWR1.
For SWR1, you can select a DME combination as follows,
depending on the number of DMEs connected.
Only one DME connected: DME1
Two DMEs connected: DME1 and DME2
Three DMEs connected: DME1, DME2, and DME3
Four DMEs connected: DME1, DME2, DME3, and
DME4
When you use both the MKS-7470X/7471X and MVE-
8000A to the MVS-7000X, DME1 is assigned to the MKS-
7470X/7471X and the selectable DME combinations are
as follows.
Only one MVE-8000A unit connected: DME1 and
DME3
Two MVE-8000A units connected: DME3 and DME4
Depending on the selected DME combination, press
[DME1] (first DME), [DME2] (second DME), [DME3]
(third DME), or [DME4] (fourth DME), turning them on.
For SWR2, the signal format cannot be changed to 1080P.
Enabling the FM Data Port of the
Switcher
With the FM data port enabled, frame memory data can be
transferred in a short time between the switcher and the
control panels.
If multiple control panels are in use, [FM Data Port Enbl]
can be turned on for only one control panel per switcher.
1
In the System >System Config menu, press [Switcher
Assign].
The Switcher Assign menu appears.
2
Using any of the following methods, select the
switcher to be set.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
The selected switcher is displayed in reverse video.
If there is only one switcher on the network, make the
setting only for SWR1 (the first switcher).
3
Press [FM Data Port Enbl], turning it on.
Notes
Notes
