Sony MVS-7000X User Manual

276
Applying Special Effects (Nonlinear Effect Settings)
Chapter 11 DME Operations
a) When split mode is H&V
b) When split mode is H
c) When split mode is V
d) When split mode is off
To set the input signal of the back page
1 In the <Back Video> group, select the signal input into
the back page.
Self: Use the same signal as the front page.
Flat: Use a flat color.
Hue Rotation: Gradually vary the hue.
2nd Ch: Use the 2nd channel video signal.
To select “2nd Ch,” it is first necessary to select
the second DME on the keyer using DME.
2 Adjust the following parameters, according to the
selected input signal.
When Flat is selected
When Hue Rotation is selected
When using a page turn effect with one channel, the
following restrictions apply.
• In an MVE-8000A HD system, when the input is for
example a title, parts of the back page other than the title
appear as black.
• For the MKS-7470X/7471X, the same restrictions as
above apply to all signal formats.
Roll Settings
There are four modes: H&V, H, V, and Off. You can select
the turn position, the radius of the turned portion, the
amount and angle of turning, and the input video for the
front and back pages.
To apply the Roll effect
Display the Roll menu.
The knobs in the Roll menu have the same functions as
those in the Page Turn menu (see page 275).
When using a roll effect with one channel, the following
restrictions apply.
• In an MVE-8000A HD system, when the input is for
example a title, parts of the back page other than the title
appear as black.
• For the MKS-7470X/7471X, the same restrictions as
above apply to all signal formats.
Cylinder Settings
You can set the degree of winding onto the cylinder, the
radius, the horizontal position of the wound image, and
front and back side output for the image.
To apply the Cylinder effect
With the Cylinder menu displayed, set the following
parameters.
The procedure for selecting the input signal in the <Back
Video> group is the same as for the Page Turn menu (see
page 275).
When using a cylinder effect with one channel, the
following restrictions apply.
• In an MVE-8000A HD system, when the input is for
example a title, parts of the inner surface other than the
title appear as black.
• For the MKS-7470X/7471X, the same restrictions as
above apply to all signal formats.
3 Angle Angle of turn –0.250 to +0.000
a)
–0.250 to +0.250
b)
–0.500 to +0.000
c)
–8.000 to +8.000
d)
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Speed Speed at
which hue
changes
–12.00 to +12.00
Notes
Knob Parameter Adjustment Setting values
Notes
Knob Parameter Adjustment Setting values
1 Radius Degree to
which image is
wound onto the
cylinder
0.00 to 100.00
2 Min R Radius of the
cylinder
0.00 to 100.00
3 Offset Horizontal
position of the
image wound
onto cylinder
–100.00 to
+100.00
Notes
