Basic Menu Operations
Chapter 2 Menus and Control Panel
a Item display
This is the name of the parameter being set in the keyboard
window.
b Input string
This is the character string being input in the keyboard
window.
c Close button
This closes the keyboard window.
d BS button
This clears the character immediately before the cursor in
the input string.
e Caps Lock button
This enables input of capital letters only.
You can enter items to be displayed on the control panel
LCD using lowercase letters, but these will be converted to
capitals for display.
MS-DOS does not distinguish case in filenames, and
therefore you are recommended to enter filenames in
capital letters.
f Shift button
This selects the characters on the shift side of the keys. The
shift is released when you enter a character.
g Space button
This enters a space character.
h Clear button
This clears all of the characters in the input string.
i Del button
This clears the character immediately after the cursor in
the input string.
j Left button
This moves the cursor one character to the left in the input
string.
k Right button
This moves the cursor one character to the right in the
input string.
l Enter button
This sets the input string as a parameter value, and closes
the keyboard window if the value has been entered
correctly. If the value has not been entered correctly, the
display color changes.
m Line feed button
After pressing the Shift button, press this button to feed a
line. The input string shows “
|”.
Names and Functions of Parts of the Color Pallet Window
When a parameter is assigned to the knobs as a
combination of luminance, saturation, and hue, pressing a
knob parameter button displays a color palette window.
1 Item display 2 Input string
4 BS button
3 Close button
0 Left button
6 Shift button
5 Caps Lock button
7 Space button
8 Clear button
9 Del button
qa Right button
qs Enter button
qd Line feed button
