Sony MVS-7000X User Manual

274
Applying Special Effects (Nonlinear Effect Settings)
Chapter 11 DME Operations
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
Kaleidoscope Settings
You can set the number of blocks, the partition reference
point and angle, horizontal and vertical offsets, a reflection
position, and other parameters.
To apply the Kaleidoscope effect
With the Kaleidoscope menu displayed, set the following
parameters.
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
To reflect the kaleidoscope image as if in a mirror
1 To reflect in the horizontal direction, press [Mirror H],
turning it on.
2 To reflect in the vertical direction, press [Mirror V],
turning it on.
To set the reflection position
1 Press [Position], turning it on.
2 Set the following parameters.
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
To cyclically repeat part of the original and its
reflection
Press [Cyclic], turning it on.
Lens Settings
You can set the shape and aspect ratio of the lens, the
angle, the magnification ratio, the curve ratio, the size, the
center position, and other parameters.
You can also choose to display only the portion of the
image that is seen through the lens.
To apply the Lens effect
With the Lens menu displayed, use the following
procedure.
1 In the <Mode> group, select the lens shape.
• Circle
•Rectangle
•Star
•Heart
•Bar
•Cross
2 Depending on the selected lens shape, set the
following parameters.
When Circle, Rectangle, Star, or Heart is selected
When Bar is selected
When Cross is selected
2V Vertical
original
center
position
–4.000 to +4.000
a)
–16.000 to
+16.000
b)
Knob Parameter Adjustment Setting values
1 Number Number of
blocks
0.00 to 100.00
2 Phase Angle of
partition
reference point
–8.000 to +8.000
3 Offset H Amount of
horizontal
offset
–4.000 to +4.000
a)
–16.000 to +16.000
b)
4 Offset V Amount of
vertical offset
–3.000 to +3.000
a)
–12.000 to +12.000
b)
Knob Parameter Adjustment Setting values
1H Horizontal
reflection
position
0.000 to 4.000
a)
0.000 to 16.000
b)
2V Vertical
reflection
position
0.000 to 3.000
a)
0.000 to 12.000
b)
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Magnify H Magnification
ratio
–100.00 to +100.00
2 Curve H Curve ratio –100.00 to +100.00
3 Size H Size 0.00 to 100.00
4 Angle Slant angle –8.000 to +8.000
5 Aspect Aspect ratio –100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Magnify H Magnification
ratio
–100.00 to +100.00
2 Curve H Curve ratio –100.00 to +100.00
3 Size H Size 0.00 to 100.00
4 Angle Slant angle –8.000 to +8.000
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Magnify H Horizontal
magnification
ratio
–100.00 to +100.00
2 Curve H Horizontal
curve ratio
–100.00 to +100.00
