136
Wipe Settings for Independent Key Transitions
Chapter 5 Wipes
Wipe Settings for
Independent Key
Transitions
You carry out independent key/downstream key transition
wipe setting operations using the Wipe Adjust menu for
each keyer.
This section describes the independent key transition wipe
settings, taking the M/E-1 >Key1 >Transition >Wipe
Adjust menu as an example.
For details, see “Independent Key Transitions” (page 84).
Basic Procedure for Independent
Key Transition Wipe Settings
Accessing the independent key transition
wipe settings menu
As an example, to access the M/E-1 >Key1 >Transition
>Wipe Adjust menu, carry out the following operations.
• In the menu control block, select the top menu selection
button [M/E 1] and select VF1 ‘Key1’ and HF6
‘Transition’ to display the Transition menu for key 1,
then press [Wipe Adjust].
• If VF1 [Key5] is shown, press the switching button at the
top of the menu, so that [Key1-4] appears, and press VF1
[Key1].
To select [M/E-4], a previous assignment in the Setup
menu is required.
Carrying out the above operation displays the M/E-1
>Key1 >Transition >Wipe Adjust menu (which will be
referred to below as simply the Key1 Wipe Adjust menu).
Selecting the independent key transition
wipe pattern
You select the independent key wipe pattern from the list
of patterns displayed in the menu.
In an independent key transition, you can only use the
standard wipe patterns (pattern numbers 1 to 24).
To select a wipe pattern for independent key1 on the M/E-
1 bank, use the following procedure.
1
In the Key1 Wipe Adjust menu, select [Pattern Select].
The Pattern Select menu appears.
2
Press the button for the desired pattern.
Setting Independent Key Transition
Wipe Modifiers
Available modifiers
You can use the following modifiers with an independent
key transition wipe.
Note that the available modifiers may depend on the
pattern you are using.
• Direction
• Edge
• Positioner
•Rotation
• Aspect ratio
• Pattern replication
Setting the wipe direction (Direction)
In the <Direction> group of the Key1 Wipe Adjust menu,
make any of the following selections.
Normal: regular direction
Normal/Reverse: alternate between regular and reverse
for each transition
Reverse: reverse direction to normal
Softening the wipe pattern edge (Soft
edge)
1
Press [Soft] in the Key1 Wipe Adjust menu, turning it
on.
2
Set the following parameter.
Setting the wipe position (Positioner)
There are two methods of setting the wipe position: using
the device control block, or in a menu.
To set the wipe position using the trackball
You can also set the wipe position using the trackball in the
device control block.
1
In the device control block, press the [M/E1] or [P/P]
button, turning it on.
The buttons in the device control block are assigned to
the wipe position setting as follows.
Notes
Notes
Knob Parameter Adjustment Setting values
1 Soft Edge softness 0.00 to 100.00
To Next Page
