24
Creation of Special Effects and Management of Data and Operations
Chapter 1 MVS-8000X/7000X Functions
3D Support
Installing the BZS-8560 switcher upgrade software in an
MVS-8000X/ 7000X, and the BZDM-8560 DME upgrade
software in an MVE-8000A/MVE-9000, enables the
processing of video in 3D mode.
For details, see “3D Support” (page 211).
Creation of Special
Effects and Management
of Data and Operations
This section introduces functions used for creation of
special effects, control of external devices or switcher
operations, and data management.
Digital Multi Effects (DME)
When used with the switcher, DME allows you to add
three-dimensional effects such as image movement,
rotation, magnification and shrinking, as well as a wide
variety of special effects.
Each channel can be used on its own or in combination
with other channels, which allows you to create advanced
effects with more complexity.
The following types of DME special effects are available.
• Edge effects: Border, Crop, Beveled Edge, Key Border,
Art Edge, Flex Shadow
• Effects for entire image: Defocus, Blur, Multi Move
• Effects for video image: Sepia, Mono, Posterization,
Solarization, Nega, Contrast, Mosaic, Mask, Sketch,
Metal, Dim and Fade, Glow
• Freeze effects
• Nonlinear effects: Wave, Mosaic Glass, Flag, Twist,
Ripple, Rings, Broken Glass, Flying Bar, Blind, Split,
Split Slide, Mirror, Multi Mirror, Kaleidoscope, Lens,
Circle, Panorama, Page Turn, Roll, Cylinder, Sphere,
Explosion, Swirl, Melt, Character Trail
• Lighting effects: Lighting, Spotlighting
• Recursive effects: Trail, Motion Decay, Keyframe
Strobe
• Background color
• Separate Sides (effects for front and back sides)
• Signal inversion (Invert effect)
• Key density adjustment
• Key source selection
Global effects
Global effects are special effects created by combining the
images of successive channels. The following types of
global effects are available.
• Combiner
•Brick
• Shadow
For details, see “DME Operations” (page 220).
