188
Misc Menu Operations
Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
Displaying a List of Transition Rates
and Changing the Settings
In the Transition menu, for each bank you can display a list
of the M/E (or PGM/PST) transition rates and independent
key (or DSK) transition rates, and change the settings.
These settings are linked to the other transition rate setting
operations.
Displaying the Transition menu
In the menu control block, press the top menu selection
button [MISC], then select VF3 ‘Transition.’
The Misc >Transition menu appears.
About the Transition menu display
The display of the independent key transition rate in the
Misc >Transition menu depends on the selection in the
<Key Transition> group of the Engineering Setup
>Switcher >Transition menu for each of the M/E and
PGM/PST banks.
When [Same] (On direction and Off direction settings
the same) is selected in the <Key Transition>
group: Only “Key” (or “DSK” in the PGM/PST bank)
appears.
When [Independ] (On direction and Off direction
settings independent) is selected in the <Key
Transition> group: “Key(On)” and “Key(Off)” each
appear. In the case of the PGM/PST bank, “DSK(On)”
and “DSK(Off)” appear.
For details, see “Settings Relating to Video Switching
(Transition Menu)” in Chapter 20 (Volume 2).
Setting the transition rate in the Transition
menu
To set the M/E transition rate
For example, to make the settings for the M/E-1 bank, use
the following procedure.
1
Press in the list in the status area of the Misc
>Transition menu, to select M/E-1.
2
In the <Transition Rate> group, press [Transition].
3
Turn the knob to set the number of frames.
When a clip transition is selected as the transition type, it
is not possible to change the transition rate in this menu.
To set the independent key transition rate
By way of example, the following is the procedure for
settings of keys 1 to 4 in the M/E-1 block.
1
Press in the list in the status area of the Misc
>Transition menu, to select M/E-1.
2
In the <Transition Rate> group, press [Key K1-K4].
To insert (on) or remove (off) keys individually, press
[Key(On) K1-K4] or [Key(Off) K1-K4].
3
Turn the knobs to set the number of frames.
To set the fade-to-black transition rate in
the Transition menu
This function is not available with the CCP-9000A.
1
In the Misc >Transition menu, press [FTB].
2
Turn the knob to set the number of frames.
Knob Parameter Adjustment Setting values
1Transition
Rate
Transition rate 0 to 999
(frames)
Notes
Knob Parameter Adjustment Setting values
1Key1 Trans
Rate
Key 1 transition
rate
0 to 999
(frames)
2Key2 Trans
Rate
Key 2 transition
rate
0 to 999
(frames)
3Key3 Trans
Rate
Key 3 transition
rate
0 to 999
(frames)
4Key4 Trans
Rate
Key 4 transition
rate
0 to 999
(frames)
Notes
Knob Parameter Adjustment Setting values
1Transition
Rate
Transition rate 0 to 999
(frames)
