DME Wipe Settings for Independent Key Transitions
Chapter 6 DME Wipes
DME Wipe Settings for
Independent Key
Transitions
You carry out independent key/downstream key transition
DME wipe setting operations using the DME Wipe Adjust
menu for each keyer.
For an overview of independent key transitions, see page
84.
This section describes the independent key transition DME
wipe settings, taking the M/E-1 >Key1 >Transition >DME
Wipe Adjust menu as an example.
Basic Procedure for Independent
Key Transition DME Wipe Settings
Accessing the independent key transition
DME wipe settings menu
As an example, to access the M/E-1 >Key1 >Transition
>DME Wipe Adjust menu, carry out the following
operation.
• In the menu control block, select the top menu selection
button [M/E 1], and select VF1 ‘Key1’ and HF6
‘Transition’ to display the Transition menu for key 1.
Next, press [DME Wipe Adjust].
If VF1 [Key5] is shown, press the switching button at the
top of the menu, so that [Key1-4] appears, and press VF1
[Key1].
To select [M/E-4], a previous assignment in the Setup
menu is required.
Carrying out the above operation displays the M/E-1
>Key1 >Transition >DME Wipe Adjust menu (which will
be referred to below as simply the Key1 DME Wipe Adjust
menu).
Selecting the independent key transition
DME wipe pattern
You select the independent key DME wipe pattern from
the list of patterns displayed in the menu.
To select a DME wipe pattern for independent key1 on the
M/E-1 bank, use the following procedure.
1 In the <Pattern Select> group of the Key1 DME Wipe
Adjust menu, press [1ch] for one-channel mode or
[2ch] for two-channel mode.
The Pattern Select menu appears.
2 Select the desired DME wipe pattern group with one of
the following buttons.
(In two-channel mode, only Page Turn and Page Roll
are selectable.)
• Slide/Squeeze: slide and squeeze
• Split/Door: split and door
• Mirror/Sphere: mirror and sphere
• Character Trail: character trail
• Wave/Ripple: wave and ripple
• Page Turn/Roll: page turn and page roll
• Frame I/O: frame in/out
• 2D Trans/3D Trans: 2D Trans and 3D Trans
• Sparkle/Split Slide: sparkle and split slide
• User Program: user programmable DME
For details of DME wipe patterns, see “Types of DME
Wipe Pattern” (page 140) and “DME Wipe Pattern
List” (page 312).
3 Press the button to select the desired pattern.
Setting Independent Key Transition
DME Wipe Modifiers
You can add modifiers such as pattern position and size for
an independent key transition DME wipe.
For introductory information, see “Setting the DME wipe
position (Positioner)” (page 146) and “Setting the DME
wipe pattern size (Size)” (page 147).
Setting the DME wipe position (Positioner)
For applicable pattern numbers, see page 142.
1 In the <Position> group of the Key1 DME Wipe
Adjust menu, press [Position], turning it on.
2 Set the following parameters.
To return the DME wipe pattern position to the
center of the screen
In the <Position> group, press [Center].
Notes
Knob Parameter Adjustment Setting values
1H Horizontal
position
–200.00 to
+200.00
2V Vertical
position
–200.00 to
+200.00
