468
Network Settings (Network Config Menu)
Chapter 18 System Setup (System)
Network Settings
(Network Config Menu)
This provides automatic configuration of all devices
connected to the Data LAN (excluding the DCU), and
displays a list of them.
To make the network settings, use System >Network
Config menu.
To display the Network Config menu
In the Engineering Setup menu, select VF1 ‘System’ and
HF1 ‘Network Config.’
The status area shows the device ID, and Control LAN and
Data LAN IP addresses for each device excluding the
DCU.
Making the Network Settings
Checking IP address automatically
1
In the System >Network Config menu, press [Auto
Config].
This automatically checks all devices (excluding the
DCU) connected to the Data LAN.
2
Once switch to another menu, then display the
Network Config menu again.
Now the status area of the System >Network Config
menu shows the results of the automatic check.
Be sure to carry out this operation after reconfiguring the
system, or after a software upgrade.
Using the NFS server
The address of the currently selected NFS server appears
in the [NFS Server Address] box in the lower status area.
When the control panel is reset, no NFS server can be used
via the Network Config menu. In this case, to use an NFS
server, make sure to carry out the following procedure.
1
In the System >Network Config menu, press [NFS
Server].
A keyboard window appears.
2
Enter the address of the server you want to use.
3
Press [NFS Mount].
Notes
Notes
