569
Tally Copy Settings (Tally Copy Menu)
Chapter 23 Setup Relating to Router Interface and Tally (Router/Tally)
DCU1: Generate tally with reference to signal input to
DCU1 port. Set the port number with the knob.
DCU2: Generate tally with reference to signal input to
DCU2 port. Set the port number with the knob.
5
Turn the knob to select the tally input port number.
6
Press [Execute].
This sets the settings made in steps 2 to 5 as the
settings for tally generation.
Modifying Tally Generation
1
In the Router/Tally >Tally Enable menu, press
[Modify].
The Modify menu appears.
2
With reference to steps 2 to 5 in the preceding section
“Making new tally generation settings,” change the
parameters as required.
3
Press [Execute].
Deleting Tally Generation Settings
1
Using either of the following methods in the Router/
Tally >Tally Enable menu, select the tally generation
entry you want to delete.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
2
Press [Delete].
Tally Copy Settings (Tally
Copy Menu)
You can copy the tally information pertaining to a
particular source to a different source.
For settings relating to the tally copy function, use the
Router/Tally >Tally Copy menu. The settings are common
to the parallel and serial tallies.
To display the Tally Copy menu
In the Engineering Setup menu, select VF6 ‘Router/Tally’
and HF5 ‘Tally Copy.’
The status area shows the tally copy status.
Making New Tally Copy Settings
1
In the Router/Tally >Tally Copy menu, select [New].
The New menu appears.
2
Turn the knob to select the copy-from source.
When setting more than one tally copy, you can
specify the copy-from source start and end addresses.
3
Specify the copy-to source address.
4
Press [Execute].
This makes the tally copy setting according to the
specifications in steps 2 and 3.
Modifying Tally Copy Settings
1
In the Router/Tally >Tally Copy menu, press
[Modify].
The Modify menu appears.
2
Use the knobs to select the copy source and copy
destination.
Knob Parameter Adjustment Setting values
5 Input No Tally input port
number
1 to 102
Knob Parameter Adjustment Setting values
1 Copy From
(From)
Copy-from source
start address
1 to 1024
2 Copy From
(To)
Copy-from source
end address
1 to 1024
Knob Parameter Adjustment Setting values
3Copy To
(From)
Copy-to source
(start) address
1 to 1024
4Copy To
(To)
Copy-to source
(end) address
1 to 1024
To Next Page
