187
Misc Menu Operations
Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
DME override
1
In the menu control block, press the top menu
selection button [MISC], then select VF1 ‘Enable’ and
HF1 ‘Port Enable.’
The Misc >Enable >Port Enable menu appears.
2
In the <DME Override> group, select the DME
override mode.
DME Override: When a switcher snapshot or effect
using a DME is recalled, forcibly select the DME
that was used when saving.
On Air Protect: The operation is the same as the
DME override function, except that a DME being
used by an M/E bank or P/P bank that is on air will
not be forcibly selected.
If effects using the same DME channel are selected
simultaneously in two or more regions, the DME is
selected with the order of precedence P/P >M/E1 >M/
E2 >M/E3 >M/E4.
Enabling or disabling control from System
Manager
By installing the BZPS-8000 System Management
Software (System Manager), you can use a computer
connected on a network for management of some switcher
data and control operations.
To enable or disable this function, use the following
procedure.
1
In the menu control block, press the top menu
selection button [MISC], then select VF1 ‘Enable’ and
HF1 ‘Port Enable.’
The Misc >Enable >Port Enable menu appears.
2
Press [System Manager].
Each time you press the button toggles between enable
and disable.
Editing Keyboard Settings
The following operations are only possible when a license
for the BZS-8050 Editing Control Software is activated.
For details of license registration, see “Installation and
Device Setup (Install/Unit Config Menu)” in Chapter 18
(Volume 2).
Enabling or disabling control from the
editing keyboard
1
In the menu control block, press the top menu
selection button [MISC], then select VF1 ‘Enable’ and
HF2 ‘Plug-In Editor.’
The Misc >Enable >Plug-In Editor menu appears.
2
In the <Control From Plug-In Editor> group, press
[Editor Enable].
Each time you press the button toggles between enable
and disable.
To enable control of the preview bus only
When control from the editing keyboard is disabled (when
[Editor Enable] is set to Disable), to enable control of the
preview bus only, press [PVW Bus Enable] in the
<Control From Plug-In Editor> group.
Safe Title Settings
Switching the safe title function on or off
1
In the menu control block, press the top menu
selection button [MISC] and select VF2 ‘Safe Title.’
The Misc >Safe Title menu appears.
2
Using any of the following methods, select the signal
to which the settings apply.
• Directly press the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob to make the setting.
• It is not possible to change the setting for the output
for which the safe title is set off in a Setup menu.
• The safe title function cannot be used for output
signals for which through mode is set to Enable in a
Setup menu.
For more information about the Setup menu settings
referred to above, see “Signal Input Settings (Input
Menu)” and “Signal Output Settings (Output Menu)”
in Chapter 20 (Volume 2).
3
Press [Safe Title] to set it on or off.
Notes
Notes
Knob Parameter Adjustment Setting values
1 Output Signal to which
the settings
apply
1 to 48
Notes
To Next Page
