Sony MVS-7000X User Manual

270
Applying Special Effects (Nonlinear Effect Settings)
Chapter 11 DME Operations
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
To reverse the ripple range
When modulation mode is Radial, Both, or Shape:
Press [Range Rev R], turning it on.
When modulation mode is Both or Angular: Press
[Range Rev A], turning it on.
Other settings
You can turn [Lock], [Form], [Random], and [Range
Envelope] on to do the following.
• Stop the waves
• Select the wave shape
• Randomize the waveform
• Smooth the range envelope when the wave range is
limited
For Lock, Form, Random, and Range Envelope functions,
see “Wave Settings” (page 264).
Rings Settings
You can set the degree of transition, the degree of
randomness in the distance moved by each block, the
amount of movement, the width of the partitions, the
degree of randomness in partition width, the center point,
the starting angle, and other parameters.
To apply the Rings effect
With the Rings menu displayed, use the following
procedure.
1 To make transition settings, press [Transition] and set
the following parameters.
2 To set the partition method, press [Partition] and set
the following parameters.
3 To set the ring center position, press [Position] and set
the following parameters.
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
4 To partition into pixels, press [Pixel], turning it on, and
set the following parameters.
Broken Glass Settings
You can set the degree of transition, the degree of
randomness in the distance moved by each block, the
amount of movement, the width of the partitions, the
degree of randomness in partition width, the center point,
the starting angle, and other parameters.
You can also fix the direction in which shards scatter.
3 Size A Amount of
ripple
modulation
along
periphery
0.00 to 100.00
4 Offset A Center of
modulation
range along
periphery
–8.000 to +8.000
Knob Parameter Adjustment Setting values
1 Transition Degree of
transition
0.000 to 100.000
2 Random Degree of
randomness in
distance
moved by
each block
0.000 to 100.000
Knob Parameter Adjustment Setting values
3 Spiral Amount of
movement
toward
periphery
accompanying
transition
–1.000 to +1.000
Knob Parameter Adjustment Setting values
1 Width Width of
partition
0.000 to 100.000
2 Random Degree of
randomness in
partition width
0.000 to 100.000
3 Angle Starting angle
of effect
–8.000 to +8.000
Knob Parameter Adjustment Setting values
1 H Horizontal
center position
–5.000 to
+5.000
a)
–20.000 to
+20.000
b)
2 V Vertical center
position
–4.000 to
+4.000
a)
–16.000 to
+16.000
b)
Knob Parameter Adjustment Setting values
1 Density Degree to
which image
disappears
around
periphery
0.00 to 100.00
2 Random Degree of
jaggies at
block edges
0.00 to 100.00
Knob Parameter Adjustment Setting values
