122
Resizer
Chapter 4 Keys
• When a mask effect is applied to a border, the
boundary becomes discontinuous, giving an
unnatural effect. Avoid applying a mask to a border.
• If mosaic or defocus is enabled, and in the <Mosaic/
Defocus Mode> group you select Video/Key, then
the mask is disabled.
Restrictions on resizer effects
Restrictions on the use of effects
Of the resizer effects, using mask, drop shadow, or wide
key border requires two units of hardware for the resizer
function.
These are called “dual resizer effects”.
In a dual resizer effect, predetermined combinations, key 1
and key 2, key 3 and key 4, key 5 and key 6, key 7 and key
8 are used.
For example, if either of key 1 and key 2 has resizer set to
On, the other key cannot be used for a dual resizer effect.
The same restriction applies when using a resizer DME
wipe in place of resizer.
Impossibility of simultaneous use within the
same keyer
The following combinations of resizer effects cannot be
simultaneously on.
• Mosaic and edge enhance
• Defocus and wide key border
• Mask and drop shadow
• Mask and wide key border
Setting rotation of the resizer
Either X or Y direction must be specified for rotation. You
cannot make rotation by combining both directions.
When rotating key 1 of the M/E-1 bank, for example, use
the following procedure.
1
Select M/E-1 >Key1 >Processed Key menu, press
[Resizer], turning it on.
2
Press [Rotation], turning it on.
The Rotation menu appears.
3
Press [X] or [Y] in the <Rotation> group to select the
direction of rotation.
4
Turn the knobs to adjust the following parameters.
• When [X] is on
• When [Y] is on
Canceling Virtual Images
If an extreme degree of perspective is set for an image, the
part of the image which is beyond the imaginary view
point of view is wrapped around to show the other side of
the image on the monitor screen. You can press [Wrap
Around], turning it on, to make a setting not to show the
virtual images.
Notes
Notes
Knob Parameter Adjustment Setting values
1 Rotation X Rotate key
horizontally
–99.0000 to
+99.0000
4 Perspective Change
perspective
0.0000 to
99.9999
Knob Parameter Adjustment Setting values
2 Rotation Y Rotate key
vertically
–99.0000 to
+99.0000
4 Perspective Change
perspective
0.0000 to
99.9999
