Sony MVS-7000X User Manual

255
Applying Special Effects (Effects on the Overall Video Signal)
Chapter 11 DME Operations
When Video/Key is selected (with SDI-interfaced
DME)
When Video is selected
.
When Key is selected (with SDI-interfaced DME)
5 To cancel black level leaking that can occur at the edge
of the screen when the Defocus effect is enabled, press
[Clean Defocus], turning it on.
Masking the Defocus effect with a selected
pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Blur Settings
Applying the Blur effect
1 In the DME menu, select VF2 ‘Video Modify’ and
HF1 ‘Defocus/Blur.’
The Defocus/Blur menu appears.
2 Press [Blur], turning it on.
On the MVE-8000A, the Glow and Blur effects cannot
be enabled at the same time. The effect which was
turned on most recently is enabled.
3 When the DME is connected through an SDI interface,
in the <Blur Mode> group, select the signal to which
you want apply the Blur effect.
Video/Key: Video signal and key signal
Video: Video signal only
Key: Key signal only
4 Set the parameters.
When the DME dedicated interface is used
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 V/K H Horizontal
defocusing of
video and
key signals
Video H value
shown
2 V/K V Vertical
defocusing of
video and
key signals
Video V value
shown
3 V/K All Horizontal
and vertical
defocusing of
video and
key signals
Video H value
shown
4 Video All Horizontal
and vertical
defocusing of
video signal
Video H value
shown
5 Key All Horizontal
and vertical
defocusing of
key signal
Key H value shown
Parameter group [2/2]
Knob Parameter Adjustment Settings values
1 Video H Horizontal
defocusing of
video signal
0.00 to 100.00
2 Video V Vertical
defocusing of
video signal
0.00 to 100.00
3 Key H Horizontal
defocusing of
key signal
0.00 to 100.00
4Key V Vertical
defocusing of
key signal
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 H Horizontal
defocusing of
video signal
0.00 to 100.00
2V Vertical
defocusing of
video signal
0.00 to 100.00
3 All Horizontal
and vertical
defocusing of
video signal
H value shown
Knob Parameter Adjustment Settings values
1H Horizontal
defocusing of
key signal
0.00 to 100.00
2V Vertical
defocusing of
key signal
0.00 to 100.00
3All Horizontal
and vertical
defocusing of
key signal
H value shown
Notes
Knob Parameter Adjustment Setting values
1H Horizontal
defocusing of
video and
key signals
0.00 to 100.00
