Multi Program 2
Chapter 10 Special Functions
Differences between Multi Program 2 Mode and Standard Mode
The differences from operation in standard mode are as
follows.
a) Keys 2 to 8 are common to main and sub.
• Allow a transition to complete before carrying out main
and sub delegation switching.
• The sub background A bus (utility 2 bus) is shared with
wipe edge border fill. Making a change to one affects the
other.
• Even if the wipe border width is set to the same numeric
value for main and sub, the same image is not obtained.
Restrictions on Using Multi Program
2 Mode
• The following functions are not available for sub:
- Data copy and swap
- Default recall (except for parametric recall)
• Re-entry is limited to five levels. Re-entry is not possible
for main and sub of the same M/E.
However, this restriction can be removed.
For details, see “Enabling re-entry between the main
and sub sides of the same M/E bank” (page 209).
• In the following cases, a transition using the fader lever
may not be performed correctly:
- When the main and sub bus toggle modes are set
differently
- For a pattern mix, preset color mix, and so on
• For an Internal bus link, GPI link, or External bus link,
the “Utility 2” bus cannot be selected.
• Screen aspect, show key, and [MCRO ATTCH ENBL]
button settings are common to main and sub.
• If a snapshot is recalled simultaneously for main and
sub, or a keyframe is executed simultaneously for main
Item Main Sub
Keys
a)
Keys 1 to 8 can be used Keys 2 to 8 only can be used
Wipes
(background)
Patterns Same as standard mode • Only standard patterns can be used
• Pattern mix is not possible
Modifiers Same as standard mode • Pairing, modulation, spring, spiral,
and split cannot be used
• Edge fill mattes are single-color
only
• Replication can be selected from
four patterns
Wipes (key) Same as wipes (background) for sub
DME wipes Use Can be used Cannot be used (Can be used, with a
setting change)
Patterns for 1 channel For a dedicated interface, each of main and sub can be used.
For the SDI interface, only one of main and sub can be used.
Patterns for 2 channels Only one of main and sub can be used
(For each M/E, the number of DMEs that can be used is the same as in
standard mode.)
Patterns for 3 channels
Backgrounds Wipe edge fill matte (including color
mix and other settings in the Matte
Adjust menu)
Wipe edge fill matte (single-color
only)
Modifiers Same as standard mode Wipe border colors are single-color
only
Transitions Key priority Cannot be used
Transition preview Cannot be used
Preset color mix Color matte or video signal selected
on the utility 2 bus
Color matte only
Snapshots Cross-point hold Utility 2 cannot be set Utility 3 is added. BKGD A/B and
Key1 cannot be set.
Control from an editor Same as standard mode Cannot be used
Operation setting for switcher GPI inputs and
outputs
Same as standard mode Cannot be used
Notes
