532
Signal Output Settings (Output Menu)
Chapter 20 Switcher Setup (Switcher)
Copying format converter input data
1
In the Switcher >Input >FC Adjust menu, press
[Copy].
The Copy/Swap >Copy >Format Converter menu
appears.
The status area shows lists of the copy source on the
left, and the copy destination on the right.
2
Select [Input] in the <Data Select> group.
3
Using any of the following methods, select the data.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
4
Press [Copy].
Signal Output Settings
(Output Menu)
For setup relating to signal outputs, use the Switcher
>Output menu.
To display the Output menu
In the Engineering Setup menu, select VF3 ‘Switcher’ and
HF3 ‘Output.’
The status area shows the output signal numbers and
names, and output signal phase for the signals output from
Output 1 to 48.
The following functions are available here.
For a format converter dedicated output, Video Clip, V
Blank, Through, Safe Title, and 4:3 Crop settings are not
possible.
• Output Assign: Assign the signals output from the
Output1 to 48 ports.
• Video Clip: Adjust the clip levels (White Clip, Dark
Clip, and Chroma Clip) for the output signals from each
of the Output1 to 48 ports.
• V Blank: Adjust the vertical blanking width for the
output signals from each of the Output1 to 48 ports. The
setting is the number of scan lines from the reference
blanking position of field 1 for the particular format
which should be masked.
• Through: Enable or disable through mode. Through
mode can be enabled for AUX1 to 48 outputs, M/E and
PGM/PST program outputs, and clean output.
• Safe Title: Enable or disable safe title, and carry out
settings for box 1 and 2, cross and grid.
• 4:3 Crop: Set the actual video image to be cropped to a
4:3 aspect ratio when an HD system has a screen aspect
ratio of 4:3.
• FC Adjust: Set the format converter outputs.
• Multi Viewer: Make settings for the two-channel multi
viewer.
Assigning Output Signals
To assign a signal to output from an output port, use the
following procedure.
1
In the Switcher >Output menu, press [Output Assign].
The Output Assign menu appears.
The status area shows the output ports and assigned
signals on the left, and a list of signals that can be
assigned on the right.
Knob Parameter Adjustment Setting values
1 Left No Select the copy
source data
1 and upwards
2 Right No Select the copy
destination data
1 and upwards
3 Num Select the
number of items
1 and upwards
Notes
To Next Page
