572
Serial Tally Settings (Serial Tally Menu)
Chapter 23 Setup Relating to Router Interface and Tally (Router/Tally)
3
Using any of the following methods, select the port bit
number.
• Press directly on the list on the left of the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
4
Turn the knob to select the source address.
5
Press [Source Address Set].
Clearing a Source Address Setting
To clear a source address setting for a particular
bit
In the Router/Tally >Serial Tally >Source Assign menu,
select the serial tally port and bit number (see steps 2 and
3 in the previous item), then press [Clear].
This clears the source address setting for the selected bit.
To clear all source address settings
In the Router/Tally >Serial Tally >Source Assign menu,
select the serial tally port, then press [All Clear].
A confirmation message appears.
• If you select “Yes,” this clears all source address settings
for the selected serial tally port.
• If you select “No,” the clear operation is canceled.
Knob Parameter Adjustment Setting values
1 Bit No Bit selection 1 and upwards
Knob Parameter Adjustment Setting values
2Source
Addr
Source address
selection
1 to 1024
To Next Page
