115
Resizer
Chapter 4 Keys
Key modify clear
When an M/E delegation button is held down, holding
down a key delegation button together returns the key
settings to the initial status settings.
For details of the initial status, see “Saving User-Defined
Settings” in Chapter 18 (Volume 2).
Resizer
Resizer allows you to apply DME-like effects such as
image shrinking, magnification and movement, rotation as
well as change of the aspect ratio, to the processed key.
The following functions are available.
• Two-dimensional transformations of keys (page 115)
• Key rotation around on the x- or y-axis
• Resizer interpolation settings (page 118)
• Resizer crop/border settings (page 118)
• Resizer effect settings (page 119)
(wide key border, drop shadow, edge enhance, mosaic,
defocus, mask)
• The image of the key manipulated by resizer has a one-
frame delay.
• Some effects of resizer are different from what you
would expect of DME effects.
Restrictions on the use of effects
There are restrictions on combined use of resizer effects
themselves and that with DME wipes.
For details, see “Impossibility of simultaneous use within
the same keyer” (page 122).
Relation between resizer and other effects
You cannot apply DME effects to a key for which the
resizer function is enabled. When one of the three
functions – resizer, DME wipe and DME effects – is
enabled, the other two are disabled.
Two-Dimensional Transformations
and Rotation of Keys
When the screen aspect ratio is 4:3 in HD format, when the
resizer is used to shrink a video image, this is applied to the
16:9 screen including the added video on the left and right
sides. Use the crop function as required to extract the 4:3
image.
Menu operations for key shrinking,
magnification, rotation and movement
For example, to shrink, magnify, rotate or move key 1 of
the M/E-1 bank, use the following procedure.
Notes
Notes
