Applying Special Effects (Edge Effects)
Chapter 11 DME Operations
If Mix Color or Ext Video selected, the border color
changes according to the mix color signal or external video
signal.
Softening the border edges
Press [Border Soft], turning it on, and set the following
parameters.
Crop Settings
Cropping the image
1 In the DME menu, select VF1 ‘Edge’ and HF1
‘Border/Crop.’
The Border/Crop menu appears.
2 Press [Crop], turning it on.
3 Set the parameters.
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
4:3 mode
16:9 mode
Signs of numeric settings
For H, V, and All settings, the sign (+/–) of the setting
need not be considered. For example, in the case of an
H setting, the value for Left is automatically regarded
as a negative value, and the value for Right as a
positive value, to display the image.
The following is an example of these settings.
4 To soften the edges of the image, press [Edge Soft],
turning it on, and set the following parameter.
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Soft Softness of inner
side of border
0.00 to 100.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1H Crop
positions on
left and right
sides
Left value shown
2V Crop
positions on
top and
bottom sides
Top value shown
3All Crop
positions on
all sides
Left value shown
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Crop position
on top side
–3.00 to +3.00 (SD)
–9.00 to +9.00 (HD)
Knob Parameter Adjustment Setting values
2 Left Crop position
on left side
–4.00 to +4.00 (SD)
–12.00 to +12.00
(HD)
3 Right Crop position
on right side
–4.00 to +4.00 (SD)
–12.00 to +12.00
(HD)
4 Bottom Crop position
on bottom
side
–3.00 to +3.00 (SD)
–9.00 to +9.00 (HD)
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1H Crop
positions on
left and right
sides
Left value shown
2V Crop
positions on
top and
bottom sides
Top value shown
3All Crop
positions on
all sides
Left value shown
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Crop position
on top side
–2.25 to +2.25 (SD)
–9.00 to +9.00 (HD)
2 Left Crop position
on left side
–4.00 to +4.00 (SD)
–16.00 to +16.00
(HD)
3 Right Crop position
on right side
–4.00 to +4.00 (SD)
–16.00 to +16.00
(HD)
4 Bottom Crop position
on bottom
side
–2.25 to +2.25 (SD)
–9.00 to +9.00 (HD)
Parameter Entered value Setting
H 1.5 Left=–1.50
Right=1.50
–1.5 Left=–1.50
Right=1.50
Parameter group [2/2]
Knob Parameter Adjustment Setting values
